Specifications
NOTE: Specifications and technical details are subject to change without prior notification.
Item Specification
Cabinet size 21.2
W x 10.8H x 19.2D cm (8.33W x 4.27H x 7.55D")
Weight 1.8 kg (4.0 lb)
Power adapter AC input: 100–240 VAC (+/-10%), ~50/60 Hz, 0.6 Amp
DC Output: 24 VDC @ 3.75 Amp
Internal voltage 24 VDC
Cycle rate Exceeds 600 cycles per minute
Time range 0.0001–9999 s
Accuracy: Within ±0.05% of the selected time setting
Repeatability: Less than 16 μs at any time setting
Foot pedal Voltage: 24 VDC
Current: 20 mA
End-of-cycle feedback circuits 24 VDC, 100 mA maximum
Cycle initiate Foot pedal, finger switch, 24 VDC signal, or mechanical contact closure
Input air pressure UltimusPlus I: 5.5–7.0 bar (80–100 psi)
UltimusPlus II: 1.7–2.4 bar (25–35 psi)
Air output UltimusPlus I: 0.7–7.0 bar (10–100 psi)
UltimusPlus II: 0–1.0 bar (0.3–15 psi)
Pressure readout accuracy UltimusPlus I: ±0.1 bar (2.0 psi)
UltimusPlus II: ±0.2 bar (0.3 psi)
Vacuum 0–1.3 inHG (0–18inH
2
O)
Vacuum readout accuracy ±0.15 inHG (±2.0 inH
2
O)
NOTE: The dispenser vacuum readout accuracy is calibrated from
0–0.88inHG (0–12inH
2
O).
Ambient operating conditions Temperature: 5–45° C (41–113° F)
Relative humidity (RH): 85% at 30° C (86° F), non-condensing
Height above sea level: 2,000 m maximum (6,562 ft)
Approvals CE, TUV, RoHS, WEEE, China RoHS
UltimusPlus Series Dispensers
11www.nordsonefd.com info@nordsonefd.com +1-401-431-7000 Sales and service of Nordson EFD dispensing systems are available worldwide.
