Operation (continued)
Exporting Programs to a USB Drive
You can use the USB port on the dispenser to export all
programs in the Program Library to a USB drive. Once
exported, the programs can then be imported to a different
dispenser.
1. Insert a USB drive into the USB port.
2. Press Programs > Export / Import Library .
3. Press Export Library to export all programs to the USB
drive.
If the export is successful, the system indicates the
following: “Export successful.” If the export fails, refer
to “Dispenser Warnings” on page50 to troubleshoot
the problem.
NOTE: Exported dispenser programs are formatted as
an *.ult file.
4. Press Home to return to the Home screen.
Importing Programs from a USB
Drive to a Dispenser
1. Insert a USB drive into the USB port.
2. Press Programs > Export / Import Library .
3. Press Import Library to import all programs on the USB
drive to the Program Library.
If the import is successful, the system indicates the
following: “Import successful.” If the import fails, refer to
“Dispenser Warnings” on page50 to troubleshoot the
problem.
NOTE: All the programs on the USB drive are imported to
the dispenser, replacing existing programs.
4. Press Home to return to the Home screen.
UltimusPlus Series Dispensers
33www.nordsonefd.com info@nordsonefd.com +1-401-431-7000 Sales and service of Nordson EFD dispensing systems are available worldwide.
