Ranges for All Editable Settings
For your reference, the following table lists all user-editable settings and their corresponding range of values.
Variable Range of Values Description or Comment
Time 0.0001–9999 (s)
Sets the open time of the dispense cycle in
seconds
Pressure
UltimusPlus I: 0.7–7.0 bar (10–100 psi)
UltimusPlus II: 0–1.0 bar (0.3–15 psi)
Sets the air pressure to the syringe barrel in psi
or bar
Vacuum 0.0–18.0 inH2O
Sets the vacuum pressure in inches of water or
inches of mercury
MultiShot
Pause Time: 0.0001–999.9 (s)
Count: 0–9999
For each cycle initiate (for example, one press of
the foot pedal), sets how many deposits (Count)
the system dispenses and how many seconds
elapse between deposits (Pause Time).
Run Limit None (0)–9999
Sets the maximum number of shots (cycle
initiates) for a program; when the Run Limit is
reached, the system stops responding to a cycle
initiate. Use Reset Count to reset the Shot Count
for a program to 0.
NOTE: In the MultiShot mode, each dispense
cycle is counted in the Run Limit.
Sleep Mode
Enabled or disabled (toggle)
Time: 5, 10, 60 (min)
If Sleep Mode is enabled, sets the Time (in
minutes) to elapse after the last dispense before
the system enters the Sleep Mode
Language
English, Chinese, French, German,
Japanese, Korean, Spanish
Sets the language
Pressure Units psi, bar, kPa Sets how the system displays pressure units
Vacuum Units inH2O, inHG, kPa Sets how the system displays vacuum units
System Clock 12 hour, 24 hour Sets how the system displays time
Password 4 digit password
Changes the password that locks and unlocks
the system
