Nortel CS 1000 User Manual

162 System configuration
5 Select SIP URI Map and enter the domain names.
--End--
Configuring SIP properties
To configure SIP properties using Element manager, complete the
following procedure.
Procedure 72
Configuring SIP properties
Step Action
1 Expand Signaling Servers properties.
2 Enter a Hostname, for example SS_Node55_Ldr.
3 Select the check box for Enable Line TPS.
4 Select SIP Only for Virtual Trunk TPS.
5 Select the check box for Enable IP Proxy/Redirect Server,if
SIP Gateway and Redirect Server (NRS) are co-resident.
6 Enter a SIP Domain Name, for example mera.ru.
7 Enter a SIP Gateway endpoint name, for example DAP1.
8 Enter the Authentication Password.
9 Select Primary for Network Routing Service Role
10 Click Save and Transfer.
Nortel Communication Server 1000
SIP DECT Fundamentals
NN43120-123 01.07
6 January 2009
Copyright © 2008-2009 Nortel Networks
.

Nortel CS 1000 Specifications

General

Brand	Nortel
Model	CS 1000
Category	Server
Language	English
