208 System administration
After the update procedure is finished, the handset continues to
use the old firmware packet.
17 When the update is complete, click Remove Ready Handsets.
18 To activate the new firmware, restart the handset.
There are two options in restarting the handset.
• If the handset is in the charger, the handset automatically
executes a restart. No manual intervention needed.
• If the handset is not in the charger and you want to activate
the new software immediately, switch off the handset and
switch it on again. After the handset switches over to the new
firmware packet, the message
Firmware Update in progress.
Do not switch off. appears.
19 After the update process is finished, clean up the handsets list
using one of the following menu items.
•
Remove Handsets
• Remove Ready Handsets
20 Click Statistics if you want an overview of the all actions that
take place. A window appears.
--End--
Central directory access tool
The Central directory access tool connects a directory to the SIP DECT
system.
Note: The Central Directory Access feature is available only for the
handsets that support it.
After the Central directory access tool is installed, the tool consists of two
services running under MS Windows. There is no user interface available.
TCP/IP Port 30160 is open for external access from the IP DECT system.
IP DECT connects to the Central directory access tool through the TCP/IP
socket that is defined in the DAP Configurator tool.
For access to the database, the handset type must support access to the
database through the menu in the handset. If the handset does not offer a
menu option to access the Central Directory, Central Directory cannot be
used on that handset type. Consult your SIP DECT supplier to find out the
handset types that support Central Directory dialling.
Nortel Communication Server 1000
SIP DECT Fundamentals
NN43120-123 01.07
6 January 2009
Copyright © 2008-2009 Nortel Networks
.
