239
.
Appendix
Location builder tool
The Location Builder tool is used to create a site map within buildings and
inside the building floors and, if necessary, lines to indicate contours or
anything else that you want to draw.
In this map you put the DAPs according to their position in the real site. A
map gives you an overview of the DAP structure in a building. You can
store this information in a file. Import this file into the DAP Sync Analyzer
tool to create an overview of the synchronization structure in a building
based on your measurements.
Use the Location builder tool
Use the steps in the following procedure to start the Location builder tool.
Procedure 118
Starting the Location builder tool
Step Action
1 To start the DAP configurator tool through the Start menu,
choose Start > All programs > DAP controller > DAP
Applications > Location Builder.
The Location builder main screen appears.
Nortel Communication Server 1000
SIP DECT Fundamentals
NN43120-123 01.07
6 January 2009
Copyright © 2008-2009 Nortel Networks
.
