Nortel CS 1000 User Manual

166 System configuration
2 Click Add.
3 Enter the L0 domain name matching the Private/CDP domain
name configured on SIP Gateway and a domain description, for
example CDP Domain.
For example, enter L0 domain name
cdp for Private/CDP domain
name cdp.mera.ru.
ATTENTION
Configured L0 domain name must be unique for SIP DECT in the
communication system.
4 Enter E.164 country code, for example 7, and E.164 area code,
for example 831.
5 Click Save.
--End--
Adding Gateway Endpoint for the signaling server
Procedure 78
Adding Gateway Endpoint for the signaling server
Step Action
1 Select Gateway Endpoints from the menu list on the left.
2 Click Add.
3 Enter the SIP Gateway endpoint name configured in the Node
properties on the signaling server, for example SS_Node55_Ldr
for Endpoint name.
4 Enter an endpoint description, for example SIP GW on the
Signaling Server.
5 Select Static SIP Endpoint for SIP support .
6 Select UDP for SIP Transport.
7 Enter the Static endpoint address (Signaling Server Node IP
address) 192.168.100.105.
8 Click Save.
--End--
Adding Gateway Endpoint for DAP redirect server
You need to choose one of the DAPs to which NRS routes all incoming
requests from SIP Gateway. This DAP further routes the incoming
requests to appropriate DAPs in the SIP DECT system. The selected DAP
is called the DAP Redirect Server.
Nortel Communication Server 1000
SIP DECT Fundamentals
NN43120-123 01.07
6 January 2009
Copyright © 2008-2009 Nortel Networks
.
