Site planning example: Able-Studio 25
If the building contains atriums, multiple floors, or floors not
all the same shape or unusual conditions, see “Multiple floor
deployment” (page 78).
5 Record the height of floors.
6 Record as much information as you can obtain about the
partitioning of floors.
7 Discuss and record the details of furniture, cupboards, and
machinery in the interior of buildings on every floor.
8 Ask about other building details as necessary and record this
information.
--End--
Identify existing cabling
Gather the following information and enter it into the work order.
Procedure 4
Identifying existing cabling
Step Action
1 Obtain the location of the telephone switching room.
2 Determine the total length of the existing cable.
3 Ask about the existing cabling from the DAPs to the IP Switch.
The wiring from the DAPs to the IP Switch must be at least UTP
Cat 5.
--End--
Assess radio coverage
Note:
If the customer requires the basestations be installed out of
sight, this can reduce the coverage capability of each basestation. It can
limit the performance of the system and substantially increase the cost.
Gather the following information and enter it into the work order.
Procedure 5
Assessing radio coverage
Step Action
1 Record areas where radio coverage is required.
2 Record areas where radio coverage is not required.
Nortel Communication Server 1000
SIP DECT Fundamentals
NN43120-123 01.07
6 January 2009
Copyright © 2008-2009 Nortel Networks
.
