Deployment tool 55
Charging the deployment tool battery
Charge the deployment tool battery for at least six hours before using.
CAUTION
Equipment Damage
Use the Nortelbattery charger. This charger is a separately
ordered item. Failure to use an automatic shutoff battery
charger can damage the battery.
Do not use the battery supplied with the CT2 deployment tool.
The CT2 and DECT batteries are not interchangeable.
Figure 34
Deployment tool battery charger
Table 6
Deployment tool battery charger key
a
battery charger (must be ordered separately)
b battery charger cable
Procedure 7
Charging the deployment tool battery
Step Action
1 Set up the deployment tool battery charging equipment.
Remove the deployment tool battery, charger, and charger cord
from the yellow case.
2 Charge the deployment tool battery.
Connect the charger cord plug into the battery. Connect the red
alligator clip to the positive lead of the charger, and the black clip
to the negative lead of the charger. Connect the battery charger
to the AC mains.
3 Remove the deployment tool battery from the charger after it is
charged.
Nortel Communication Server 1000
SIP DECT Fundamentals
NN43120-123 01.07
6 January 2009
Copyright © 2008-2009 Nortel Networks
.
