26 Technical Data
92 / 106 Instruction Manual Keratograph 5M (G/77000/XXXX/EN – Rev05)
26 Technical Data
Gauge head
LED illumination
Measuring range 3 to 38 mm
9 to 99 dpt
Accuracy ± 0.1 dpt
Reproducibility ± 0.1 dpt
Number of rings 22
Working distance 78 – 100 mm
Number of analyzed
data points
22000
Camera Digital CCD color camera
Dimensions H x W x D 275 x 320 – 400 x 480 – 510 mm
Weight 3.2 kg (measuring equipment only)
6.1 kg (with X-Y stage)
Interface USB
Power supply 24 V DC; 2.1 A
Voltage 90-264 V AC
max. Electric energy
consumption
18 W
Serviceable life expectancy 10 Years
Illumination Color Wavelength
Fluo blue 465 nm
Ring Illumination infra red 880 nm
Meibo infra red 840 nm
Fixation red 660 nm
Glare ring white -
Tear Film white -
Ring Illumination white -
