3 – 246
Chapter 3 Removal and Replacement Procedures (RRPs)
Removal
1) Remove the COVER REAR 500/COVER REAR 250 (PL10.2.21/9.1.12). (RRP10.9/9.4)
2) Remove the COVER REAR (PL1.1.3). (RRP1.1)
3) Remove the FUSER ASSY (PL8.1.20). (RRP8.8)
4) Remove the BTR ASSY (PL8.1.21). (RRP8.10)
5) Remove the FAN MAIN (PL12.1.10). (RRP12.6)
6) Release the hook of the CHUTE TRANSFER.
7) Shift the CHUTE TRANSFER in the direction of the arrow, and remove it from the frame.
Replacement
1) Shift the CHUTE TRANSFER in the opposite direction of the arrow to install the frame, and secure
it using a hook.
Do not tighten the screw to the left side hole of the CHUTE TRANSFER.
2) Install the FAN MAIN (PL12.1.10). (RRP12.6)
3) Install the BTR ASSY (PL8.1.21). (RRP8.10)
4) Install the FUSER ASSY (PL8.1.20). (RRP8.8)
5) Install the COVER REAR (PL1.1.3). (RRP1.1)
There are 2 kinds of screws, make sure they are put in the right place.
6) Install the COVER REAR 500/COVER REAR 250 (PL10.2.21/9.1.12). (RRP10.9/9.4)
