Oki B6200 User Manual

1 - 75
Chapter 1 Troubleshooting
FIP2.19 Electrical Noise
Step Check Yes No
Possible causative parts:
HVPS/MCU (PL12.1.19)
GUIDE ASSY CRU R (PL8.1.25)
FUSER ASSY (PL8.1.20)
EP CARTRIDGE
HARNESS ASSY ANT (PL8.1.24)
HARNESS ASSY AC100V/200V (PL12.1.8)
HARNESS ASSY LVPS (PL12.1.1)
Option 550 Paper Feeder
PWBA FEEDER 550 (PL20.1.34)
PWBA DUPLEX (PL21.1.32)
1
Checking a foreign noise
Are there any other electrical appliances within 3 m of the
printer, such as generators, radios and appliances with
motors?
Either turn off the other electrical appliances, or re-locate
the printer at least 6 m from other appliances.
Does the electrical noise problem still occur?
Go to step 2. End of work
2
Checking AC ground
Is AC power supply outlet wired and grounded
appropriately?
Go to step 3.
Request the client
to fix AC power
supply outlet.
3
Checking HARNESS ASSY AC100V/200V
Is the cable connected to HARNESS ASSY AC100V/200V
appropriately grounded?
Go to step 4.
Install the ground
screw
appropriately.
4
Checking after replacing EP CARTRIDGE
Replace EP CARTRIDGE.
Does the electrical noise problem still occur, after
replacement?
Go to step 5. End of work
5
Checking GUIDE ASSY CRU R (1)
Does the Plate Earth of GUIDE ASSY CRU R contact
terminals on HVPS/MCU appropriately?
Go to step 6.
Replace GUIDE
ASSY CRU R.
(RRP8.13)
6
Checking GUIDE ASSY CRU R (2)
Remove EP CARTRIDGE.
Remove GUIDE ASSY CRU R. (RRP8.13)
Is the Plate Earth of GUIDE ASSY CRU R normal and not
damaged or soild, or there is no disturbing object?
Go to step 7.
Clean the plate or
replace GUIDE
ASSY CRU R.
(RRP8.13)
7
Checking HARNESS ASSY ANT for continuity
Disconnect P/J15 from HVPS/MCU.
Is J15 <=> J150 continuous normally?
Go to step 8.
Replace
HARNESS ASSY
ANT.

Oki B6200 Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	10.2 s
Print speed (black, normal quality, A4/US Letter)	24 ppm
Internal memory	128 MB
Processor model	PowerPC
Maximum internal memory	640 MB
Sound power level (standby)	50.3 dB
Total input capacity	400 sheets
Total output capacity	500 sheets
Maximum print size	210 x 297 mm
Media weight (tray 1)	60 - 216 gsm
Paper tray media types	Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Power requirements	230VAC +/-10%, 50/60Hz +/-2%
Compatible operating systems	Windows 98, 98SE, ME, NT4.0, 2000, XP
Maximum duty cycle	75000 pages per month
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	15 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	422 x 455 x 324 mm
