2 - 28
Chapter 2 Operation of Diagnostic
DC612 PatternPrt
Description: Prints a test pattern output from a pattern generator built into the machine.
• The message that printing is in progress is displayed on the message area during
pattern output.
• Perform jam/fail detection. If any error is detected, an operation stops in the same
way as the normal mode, but a message of Recovery is not shown. If a failure
occurs, a chain-link No. is shown, but History is disabled.
<Changing a setting item>
Prepare paper in the tray in advance.
Procedure:
1. Enter the Diag (C/E) mode, and select [Diag. Menu Fault Diag.] in the same hierarchical level using
the " ↓ " key.
2. Select the [Fault Diag. DC140 Monitor] screen in a lower level using the " → " key.
3. Select [Fault Diag. DC612 PatternPrt] in the same hierarchical level using the " ↓ " key.
4. Select the setting item screen [DC612 PatternPrt Qty 01] using the " → " key.
If you want to execute an output without changing any setting item, press the " ↓ "
key several times until [DC612 PatternPrt If OK press SEL] is shown, and press the
"FEED / SELECT" key to execute a test pattern output.
5. Show the number of copies screen using the " → " key.
6. Specify the number of copies to output.
• To set the number of copies, move the cursor using the " ← " or " → " key and change a
numerical value using the " ↑ " or " ↓ " key.
When the cursor is positioned at the left end of the copies field, pressing the " ← "
key allows you to return to the [DC612 PatternPrt Qty 01] screen in an upper
hierarchical level.
7. The number of copies is fixed by pressing the "FEED / SELECT" key. Then, "*" is marked at the
right end of the copies field.
8. Select the setting item screen [DC612 PatternPrt Tray Tray 1] using the " ↑ " or " ↓ " key.
