Oki B721 Maintenance Manual

Oki Data CONFIDENTIAL
45487001TH Rev.1
4-26 /
4. Maintenance menus
Table 4-4
Panel display Driven unit Condition
ID MOTOR ID MOTOR
ID Fan1
ID Fan2
POW FAN
ID is removed
FUSER MOTOR Fuser Motor -
REGIST CLUTCH Hopping Motor
Regist1 Clutch
-
REGIST2 CLUTCH Hopping Motor
Regist2 Clutch
-
T1 HOP CLUTCH Hopping Motor
Tray1 Hopping Clutch
-
MPT HOP CLUTCH Hopping Motor
MPT Clutch
-
DUPLEX MOTOR Duplex Motor Duplex unit is installed
DUPLEX MOTORREV Duplex Motor Duplex unit is installed
DUPLEX CLUTCH Duplex Motor
Duplex Clutch
Duplex unit is installed
T2 HOP CLUTCH Tray2 Hopping Motor
Tray2 Hopping Clutch
Tray2 is installed
T2 REG CLUTCH Tray2 Hopping Motor
Tray2 Regist Clutch
Tray2 is installed
T2 LIFT_UP MOTOR Tray2(LCF) Lift up Motor LCF is installed for Tray2
T3 HOP CLUTCH Tray3 Hopping Motor
Tray3 Hopping Clutch
Tray3 is installed
T3 REG CLUTCH Tray3 Hopping Motor
Tray3 Regist Clutch
Tray3 is installed
T3 LIFT_UP MOTOR Tray3(LCF) Lift up Motor LCF is installed for Tray3
T4 HOP CLUTCH Tray4 Hopping Motor
Tray4 Hopping Clutch
Tray4 is installed
T4 REG CLUTCH Tray4 Hopping Motor
Tray4 Regist Clutch
Tray4 is installed
POW FAN TEST Low Volt Fan -
FUSER FAN TEST Fuser FAN -
ID FAN TEST ID Fan -
ID FAN2 TEST ID Fan2 -

Oki B721 Specifications

General

Print Technology	LED
Resolution	1200 x 1200 dpi
Processor	533 MHz
Memory	256 MB
Connectivity	USB, Ethernet
Duplex Printing	Standard
