In this chapter, the procedures for replacement of parts and assemblies and units are described.
The replacement procedure is described by removal of the parts. Please install the new parts with following the
replacement procedure in reverse order.
The parts (such as
①
,
②
)shown in this manual are different from the parts used in the Disassembly for
Maintenance figure (4548700TL) and RSPL (45487001TR).
3.
Component replacement
3.1 Precautions on component replacement ....................................3-2
3.2 Method of component replacement ............................................3-4
3.3 Portions Lubricated ...................................................................3-27
