4. Maintenance menus
4.2 Maintenance Utility
The adjustments described in table 4-2 should be made by using Maintenance Utility. Details
on the utility are as follows:
(1) Maintenance Utility operation manuals:
42678801FU01 Version 30.6 or higher (Japanese)
42678801FU02 Version 30.6 or higher (English)
(2) Maintenance Utility program:
Applicable operating
system
File name Part number
Win2000/XP/Vista/7
(Japanese/English)
MuWin.zip 42678801FW01 Version 1.42.0 or higher
Table 4-2 Maintenance Utility Adjustment Items
Item Adjustment
Section in
Maintenance
Utility Operation
manual
Operation from
operator panel
(section in this
maintenance manual)
1 Board
Replace-
ment
Copies the information from the
EEPROM on the PU/CU board, and
copies the EEPROM setting value on
PU/CU board.
Purpose: To copy the information
stored on the EEPROM on the PU/CU
board when the PU/CU board needs
to be replaced with another one due to
maintenance.
Section
2.4.1.1.9
Unavailable
2 Serial
Number
Information
Setting
Rewrites the serial number recorded
on the PU, and Selects the printer
serial number recorded on the CU,
output mode, and rewrites the device
serial number.
Purpose: To configure a maintenance
replacement board to which the
information on the PU/CU board
cannot be copied (due to an interface
error).
Section
2.4.1.1.10.3
Unavailable
Item Adjustment
Section in
Maintenance
Utility Operation
manual
Operation from
operator panel
(section in this
maintenance manual)
3 Factory/
Shipping
Mode
Switches between Factory and
Shipping modes.
Purpose: To configure a maintenance
replacement PU/CU board to which the
information on the EEPROM on the PU/
CU board cannot be copied (due to an
interface error). The maintenance board
is set to the Factory mode usually by
default and, by using this function, must
be set to the Shipping mode.
Section
2.4.1.1.10.4
Section 6.3.2.10
4 Board
items
setting
information
Checks serial number information and
the Factory/Shipping mode.
Section
2.4.1.1.7
Unavailable
5 Network
Software
Updates the NIC software. Section
2.4.2.2.17
Unavailable
6 Mac
address
setting
Sets the Mac address Section
2.4.2.2.5
Unavailable
7 Counter
mainte-
nance
function
Copies the counter value of each
consumable:
Drum counter
Fuser counter
Belt counter
Toner counter
Purpose: To copy the counter value of
each consumable in the printer to use
in another printer.
Section
2.4.1.2.1
Unavailable
8 Brand/PnP
information
Sets or checks the (CU) destination,
device identification and USB
identification.
Section
2.4.1.2.9
Section 6.4.3
9 Network
Log Save
function
Stores Network log files. Section
2.4.2.2.14
Unavailable
