Oki Data CONFIDENTIAL
45487001TH Rev.1
4-27 /
4. Maintenance menus
4.3.2.5 Test print
The test printing is used for printing test patterns stored in the PU. Other patterns are stored
in the controller.
This test print cannot be used to check the print quality.
Diagnosis for the abnormal print image should be performed in accordance with section 8.
1. Enter the self-diagnostic mode (level 1) and, until TEST PRINT appears on the
upper display, press the MENU
or MENU button (the MENU button displays
the next test option and the MENU
button displays the preceding test option).
Then press the ENTER button.
2. A setting option used only in test printing appears on the lower display. Press
the MENU
or MENU button until the option to select appears (the MENU
button displays the next option and the MENU
button displays the preceding
option). Then press the ENTER button. (Go to step 5 when set to its default, the
option does not need to be set).
3. Keep pressing the MENU
, MENU key, and press the ENTER key at the
menu item set by step 2. Then, the setting item is displayed in the upper row of
display area, and the setting value is displayed in the lower row of display area.
Pressing the MENU
button displays the next setting and pressing the MENU
button displays the preceding setting (the setting last displayed takes effect.
By pressing the BACK button, the setting is accepted, step 2 being restored.
Repeat step 3 when necessary.
TEST PATTERN
1
Display Settings Default Function
PRINT
EXECUTE
- - Starts printing with the press of the ENTER
button, and ends printing with the press of the
CANCEL button.
TEST
PATTERN
0 0 0 to 15: Prints a blank page.
TEST
CASSETTE
TRAY1 TRAY1 Select the paper feed source.
Not displayed when the tray 2 is not installed.
Not displayed when the tray 3 is not installed.
Not displayed when the tray 4 is not installed.
TRAY2
TRAY3
TRAY4
MPT
PAG E 0000 0000 Sets the number of test copies printed
MEDIA MEDIA TYPE PLAIN PAPER Changes the setting of a TRAY selected in
TEST CASSETTE.
If CUSTOM SIZE is not selected in MEDIA
SIZE, CUSTOM LEN, and CUSTOM WIDTH
are not displayed.
MEDIA WEIGHT MEDIUM LIGHT
MEDIA SIZE Letter
CUSTOM LEN 210
CUSTOM WIDTH 297
MEDIA CHECK ENABLE Sets ENABLE/ DISABLE of the paper size
check.
DUPLEX 2 PAGES STACK 2 PAGES
STACK
Prints duplex two pages stack layout printing.
2 PAGES STACK: Disables duplex printing
OFF: Performs simplex printing.
1 PAGES STACK: Prints duplex one page
stack layout printing.
If DUPLEX is not installed, DUPLEX is not
displayed.
OFF
1 PAGE STACK
