Oki Data CONFIDENTIAL
45487001TH Rev.1
6-68 /
6. Troubleshooting procedure
6.5.3.(2) Stain on white print. (Refer to Figure 6-2 B.)
(2-1) Stain on white print (Partial stain)
Check item Check work
Actions to be taken
at NG
(2-1-1) ID unit
Exposure of drum
to light
Is the drum left in a circumstance in which
drum surface is exposed to direct light for a
long time?
Replace the ID
unit.
If any attempt
of using new ID
unit as a trial
is going to be
made, be sure to
use the System
Maintenance
Menu FUSE
KEEP MODE.
Leakage of toner Does toner leak out from either ID unit or from
toner cartridge?
Replace the
ID unit or toner
cartridge.
If any attempt
of using new ID
unit as a trial
is going to be
made, be sure to
use the System
Maintenance
Menu FUSE
KEEP MODE.
Check item Check work
Actions to be taken
at NG
(2-1-2) Fuser unit
Offset toner of the
fuser unit
Check if the offset toner of the previous
printing is left adhered on the fuser unit or not,
by visual inspection.
Repeat bli nd
printing using
unwanted media
until offset toner
is created on
print media.
Alternately
replace the
fuser unit. If any
attempt of using
new fuser unit as
a trial is going to
be made, be sure
to use the System
Maintenance
Menu FUSE
KEEP MODE.
(2-2) Stain on white print (overall stain)
Check item Check work
Actions to be taken
at NG
(2-2-1) Print media
Type of print media Check to see that the print media which is
used for printing is not a specially thin media.
Use the normal
paper.
(2-2-2) High voltage terminal
ID unit terminal Check that the high voltage terminal of the ID
unit is contacting with the Contact Assembly
normally by visual inspection. (Refer to Figure
6-3.)
Replace the ID
unit or correct
the high voltage
terminal.
If any attempt
of using new
ID unit as a
trial is going
to be made,
be sure to use
the System
Maintenance
Menu FUSE
KEEP MODE.
To Next Page
