1. Configuration
1.2 Printer configuration
The internal part of the printer is composed of the following sections:
• Electrophotographic processing section
• Paper paths
• Controller (a combination PU/CU board)
• Operator panel
• Power supplies (high-voltage power supply/low-voltage power supply)
Figure 1-2 represents the configuration of the printer.
Figure 1-2
