45487001TH Rev.1

2-6 /

Oki Data CONFIDENTIAL

2. Installation

2.5 Assembly procedure

2.5.1 Assembly of the printer main unit

Unpacking

Personal injury may occur.

Sincetheprinterweightsapproximately27kg,itshouldbeliftedbytwoormorepeople.

Note! • Be sure to use the consumables or maintenance units provided with this

printeratrst.Otherwise,thelifeoftheconsumablesormaintenanceunits

may not be displayed correctly, or you may not be able to use them later.

 • Theprintcartridge(thegreentube)isverydelicate.Handleitcarefully.

 • Do not expose the print cartridge to direct sunlight or very bright interior

light (approximately more than 1500 lux).Even under the normal interior

light, do not leave it for more than 5 minutes.

 • Packaging and cushioning material are needed if transporting the printer.

Donotthrowthemaway.

(1) Remove your printer from the boxand remove all cushioning materials and the

plastic bag from your printer.

(2) Removethetwostripsofprotectivetapeontherightsideandatthebackofyour

printer.

Protective tape

(3) Insertyourngerintotherecessontherightsideoftheprinterandpullthe

frontcoveropenlevertoopenthefrontcoverforward.

Note! Openthefrontcovergently.Ifyouopenitrapidly,theMPTraymayopen.

(4) FortheES7131/MPS5501b,removetheprotectivetapeandorangestopper.

(5) Turntheblueleveroftheprintcartridgefullyinthedirectionofthearrow.

Front cover

Front cover open lever

Protection tape

Stopper

Lever(blue)
