Oki Data CONFIDENTIAL
45487001TH Rev.1
6-24 /
6. Troubleshooting procedure
Panel display Cause Check details
Result
Solution
Service Call
042: Error, 043:
Error, 045: Error
Flash File System
Error
Failed access to Flash
set directly on PU/CU
board.
Run forced
initialization of
Flash.(Note that
NIC- F/W and
Mac address is
deleted.After the
initialization,it is
need to download
NIC-F/W and /
or Mac address
by Maintenance
utility.)Press"+”,"-
”,"CAN-CEL”to
turn power ON .
Replace the PU/CU
board if symptom
does not change.
Service Call
049: Error
LED head type
(resolution) error
LED Head type was
mismatched with CU
and Engine.
1) Replace the PU/
CU board with
the one for the
proper head.
2) Replace with a
head of proper
resolution.
Service Call
051: Error
CU Fan Error
Abnormal CPU
cooling fan on PU/
CU board.
Is CU Fan connector
set properly?
Is error recovered by
replacing fan?
No
Ye s
No
Connect Properly.
Replace fan.
Replace the PU/
CU board.
Power Off/On
052: Error
DMA Abort Error
detected in Image
processor.
Does error reoccur? Ye s
Power Off/On.
Replace the PU/
CU board.
Service Call
067: Error
SleepMode
Interface Monitor I/F
error with CU F/W.
Does error reoccur? Ye s
Power Off/On.
Replace the PU/
CU board.
Panel display Cause Check details
Result
Solution
Service Call
069: Error
The NIC device had
not worked correctly. Does error reoccur? Ye s
Power Off/On
Replace the PU/
CU board.
Power Off/On
070: Error
PSE firmware fault
was detected. Does error reoccur? Ye s
Power Off/On.
Replace the PU/
CU board.
Power Off/On
072: Error
Engine I/F error
between PU-CU. Does error reoccur? Ye s
Power Off/On.
Replace the PU/
CU board.
Power Off/On
073: Error
Video Error; Fault
detected when
image data was
extended.
Does error reoccur? Ye s
Power Off/On.
Replace the PU/
CU board.
Power Off/On
075: Error
Video Error; Fault
detected when
image data was
extended.
Does error reoccur? Ye s
Power Off/On.
Replace the PU/
CU board.
Power Off/On
077: Error
The video
decompress fault
was detected on
the image data
expansion.
Does error reoccur? Ye s Replace the PU/
CU board
Service Call
081: Error
The CU initializer
detected an error in
the backuped data.
Does error reoccur? Ye s
Power Off/On.
Replace the PU/
CU board.
Service Call
104: Error
Engine EEPROM
setting check was
OK when power ON.
Then detect read/
write error.
Does error reoccur? Ye s
Power Off/On.
Replace the PU/
CU board.
Service Call
106: Error
Abnormal engine
control logic. Does error reoccur? Ye s
Power Off/On.
Replace the PU/
CU board.
Service Call
112: Error
Detected illegal 2nd
Tray.
Is a 2nd Tray provided
for this model installed?
No Install a correct
2nd Tray.
Service Call
113: Error
Detected illegal 3rd
Tray.
Is a 3rd Tray provided
for this model installed?
No Install a correct 3rd
Tray.
Service Call
114: Error
Detected illegal 4th
Tray.
Is a 4th Tray provided
for this model installed?
No Install a correct 4th
Tray.
To Next Page
