42615101TH Rev.8 107 /
Oki Data CONFIDENTIAL
4.3 Parts to lubricate
This section shows parts to lubricate. It means that lubricating to parts other than mentioned is
prohibited.
It is not necessary to lubricate in removing or installing. However, specified lubrication oil has to
be used to lubricate if oil is wiped off.
Inbrication work
(1) Mark and name of the Iubrication oil
EM-30L : Molycoat EM-30L
HP-300 : Molycoat HP-300
PM : Panmotoroil 10W-40 or ZOA 10W-30
(2) Standard of amount of grease
Class
Amount of grease(cc)
W(mm)
Sample
SABCDEF
0.0005 0.003 0.005 0.01 0.03 0.05 0.1
1.24 2.25 2.67 3.37 4.86 5.76
W
7.26
To Next Page
