Oki C5200 - Right Side Cover

42615101TH Rev.8 74 /
Oki Data CONFIDENTIAL
4
3
1
2
(loosen)
4.2.2 Right Side Cover
Except C5510
(1) Open the top cover 1.
(2) Open the feeder unit 2.
(3) Loosen the screw 3 to detach the right side cover 4.(Tool No.1)
Figure 4-2-2-1 Right Side Cover
