42615101TH Rev.8
92 /
Oki Data CONFIDENTIAL
4.2.10
Controller Panel Assy
(1)
Open the top cover.
(2)
Open the feeder unit.
(3)
Remove the right side cover (see section 4.2.3).
(4)
Remove the plate-shield Assy [see section 4.2.7, step (2)].
(5)
Make Control Panel Assy connector removal.
(6)
Remove the four screws (golden)
1
, then detach the Control Panel Assy
2
.(Tool No.1)
Figure 4-2-10 Control Panel Assy
1
1
2
1
1
2
C5510
C
540
0/C5200/C5150/
C3200n
91
