5.4.2.5 Test printing
This self-diagnostic is used when PU-inside test patterns are printed. The other test patterns are
in controller’s storage.
This printing can not be used for confirmation of print quality.
Refer to Chapter 7 for diagnosing of the trouble images.
1. Go into the self-diagnostic (level 1) mode, press the MENU+ or MENU- key until “TEST PRINT”
comes into view in the upper display, and press the ENTER key (the MENU+ key is for test item
increment, and the MENU- key for test item decrement).
2. Items applied only to test printing are shown on the lower display. Press the MENU+ or MENU-
key until an item to be set appears, and hit the ENTER key (the MENU+ key is for item increment,
and the MENU- key for item decrement) [When items need not be set (must be left at their
defaults), go to step 5].
3. Press the MENU+ or MENU- key and, when the item that has been set in step 2 is reached,
press the Enter key. The item and its setting are displayed on the upper and lower panel,
respectively. The setting is incremented by pressing the MENU+ key, and decremented by
pressing the MENU- key (the last displayed setting is applied). Pressing the BACK key
determines the setting, restoring the view of step 2. Repeat step 3 as necessary.
• Values in shaded areas are initial settings. Values established are applicable only to
this test mode (they are not written into EEPROM).
TEST PATTERN
1
Display
PRINT EXECUTE
TEST PATTERN
CASSET
PAG E
COLOR
DUPLEX
MONO SSPEED
COLOR SPEED
Function
Starts printing at the press of the ENTER key, and ends the
printing at the press of the CANCEL key. (Page basis)
0: Prints a blank page.
1 to 7: (Print a pattern).
8 to 15: Print a blank page.
Selects a unit in which paper is to be loaded.
When the printer is not equipped with the tray 2, TRAY2 is not
displayed.
Sets the number of test pages printed.
Selects color or monochrome printing.
Performs two-page stack duplex printing.
Establishes duplex-off printing.
Performs one-page stack duplex printing.
Sets monochrome print speed.
LOW : 20ppm
HIGH :
24ppm (C5400/C5200 only)
DEFAULT : 20ppm
Sets color print speed.
LOW : 12ppm
HIGH :
16ppm (C5400/C5200 only)
DEFAULT :
12ppm (C5150/C3200n),
16ppm (C5400/C5200)
Set Value
—
0
TRAY1
TRAY2
FF
0000
ON
OFF
2 PAGES STACK
OFF
1PAGES STACK
DEFAULT
LOW
HIGH
DEFAULT
LOW
HIGH
