42615101TH Rev.8
90 /
Oki Data CONFIDENTIAL
3
3
3
5
4
2
3
1
4.2.9
Top Cover
Except C5510
(1)
Open the top cover assy.
(2)
Remove the ten screws (black)
1
to remove the guide-paper eject
2
.(Tool No.1)
(3)
Remove the ten screws (black)
3
to detach the cable cover
4
and the top cover
5
.
(Tool No.1)
Figure 4-2-9-1 Top Cover
89
91
