Unit
Circuit Diagram
Illustration
Resistance
1. Upper Roller Side
Between pins “1” and “7”
: About 10
Ω
Between pins “2” and “3”
: About 590k~5338k
Ω
(0~43˚C)
Between pins “5” and “6”
: About 190k~981k
Ω
(0~43˚C)
Between pins “8” and “9”
: About 23.1k~162k
Ω
(0~43˚C)
Between pins “11” and “12”
: Open
Fuser Unit
Upper roller Heater
Thermostat
Upper thermistor
Lower thermistor
Frame thermistor
Fuse
Pins
241
243
