42615101TH Rev.8 49 /
Oki Data CONFIDENTIAL
Load Paper in Paper Cassette
(1) Slide out the paper cassette.
Note!
Do not remove the rubber from the plate.
(2) Place the paper stopper in the position of the size of print paper.
Paper Guide
Paper Stopper
Plate
(3) Sufficiently loosen the paper, and jog the paper so as that its edges line up.
(4) Load the paper face down in the paper cassette.
Note!
• Print paper must be placed in the paper cassette so as to touch sides of the paper
cassette.
• Loaded print paper must not exceed the position pointed by the inverted triangles
(
▼▼)(300 sheets for 70-kg paper).
(5) Secure the paper with the paper guide.
(6) Slide the paper cassette back in.
Paper life display
Paper guide
Place Print side down.
