Oki Data CONFIDENTIAL
4. Component replacement
EM-30LP Class S
After assemble to , apply a minimum amount of
MOLYKOTE (EM-30LP) to the sliding portions of and
(the hatched areas).
Method of amount grease
Not allowed to stain the
area with grease.
43301601PA Roller-Assy. -BIAS(FU)C -1 43894903PA Cassette-Assy-FX757
Shaft-Liftup
Shaft-Liftup
Plate-Receive
Plate-Receive
EM-30LP Class B
Apply a small amount of MOLYKOTE
(EM-30LP) to sliding portions of sheet metal
and shaft (the hatched area).
