7. Troubleshooting and repair procedure
7.7 Paper cassette switches versus Paper size correspondence table
Dial display size Bit No.
TRAY1~4 1 2 3 4
Cassette: none H H H H
Legal 14" H L H L
Legal 13.5" H L H H
Legal 13" L L L H
Letter L L L L
Executive L L H L
Blank L L L L
Folio H H L L
A4 L H L L
B5 L H H L
A5 H H H L
Not used L L H H
Not used L H L H
Not used H H L H
Not used H L L H
Not used L H H H
Not used H L L L
* When switch is pressed: Low
