45376001TH Rev.1
82 /
Oki Data CONFIDENTIAL
4. Component replacement
4.2.15 Board MFH
(1) Remove the Frame Assy Top Front. (See section 4.2.14)
(2) Disengage the claws(2 places) on the of Board MFH
and remove the Board
MFH
.
