45376001TH Rev.1
126 /
Oki Data CONFIDENTIAL
5. Maintenance Menu
4. Repeat steps 2 and 3 as required.
5. Pressing the [4] terminates the test. (Returns to the status of step 1.)
Color registration correction test items
Display Details
REG ADJ EXECUTE Executing the color registration correction
REG ADJ RESULT Referring to result of the color registration correction
BLT REFLECT TEST Executing judgment of GOOD/BAD of reflectance
rate of color registration correction belt
BLT REFLECT RSLT Referring to result of the judgment of GOOD/BAD of
reflectance rate of color registration correction belt.
5.2.1.7 Density correction test
This self-diagnostic menu item is used to test the density correction function of a printer,
and to refer to result of the test execution.
At the same time, GOOD/BAD of the density correction function is judged by executing
this test.
If an error is issued, correct it by following section 2 "Density correction method overview".
1. Enter the self-diagnostic mode (level 1) and keep pressing the [2] or [8] key until
the following message is displayed.
DENS ADJ TEST
2. When the [6] key is pressed, the following message is displayed. Keep pressing
the [2] or [8] key until the target item is displayed.
DENS ADJ TEST
DENS ADJ EXECUTE
3. When the [6] key is pressed, test of the item that is displayed on the panel is
executed.
<<During execution of REG ADJ EXECUTE>>
The density correction test is executed. (The [DATA] lamp flashes.)
When the test is complete, the test result (OK or error name) is displayed in the
upper row of the display area, and ****RESULT is displayed in the lower row of
the display area
OK
DENS ADJ RESULT
[
When the [
2
] key is pressed, the test results are displayed by incrementing them.
When the [8] key is pressed, the test results are displayed by decrementing
them.
Pressing the [4] key returns the screen to the state of step 2.
To Next Page
