45376001TH Rev.1
119 /
Oki Data CONFIDENTIAL
5. Maintenance Menu
5.2.1.5 Test print
This self-diagnostic menu is used to print the test pattern that is built inside PU. Other test
patterns are stored in the controller.
This test print cannot be used to check the print quality.
Diagnosis for the abnormal print image should be performed in accordance with section 7.
1. Enter the self-diagnostic mode (level 1) and keep pressing the [2] , [8]key until "TEST
PRINT" is displayed in the upper row of the display area. Then, press the [6] key. (Pressing
the [2] key increments the test item and pressing the [8] key decrements the test item.)
2. The setting items that can be applied to the test print only is displayed in the lower row
of display area. Keep pressing the [2], [8] key until the desired menu item is displayed.
(Pressing the [2] key increments the test item and pressing the [8] key decrements the
test item.) (If all setting items need no entry [Default setting], go to step 5.)
3. Keep pressing the [2], [8] key, and press the [6] key at the menu item set by step 2.
Then, the setting item is displayed in the upper row of display area, and the setting value
is displayed in the lower row of display area.
Pressing the [2] key increments the setting value. Pressing the [2]key
decrements the setting value. (The setting value that is displayed at last is
applied.) Pressing the [4] key determines the entry value, and returns to step 2.
Repeat step 3 as required.
TEST PATTERN
1
Display Setting value Function
PRINT EXECUTE – Pressing the [6] key starts print/Pressing the [#] key
terminates print. (In units of page)
TEST PATTERN 0 0: White paper print
1~26: Refer to next page. (Pattern print)
TEST CASSETTE TRAY1 Selecting source of paper supply.
If the TRAY 2 is not installed, TRAY2 is not
displayed.
If the TRAY 3 is not installed, TRAY3 is not
displayed.
If the TRAY 4 is not installed, TRAY4 is not
displayed.
TRAY2
TRAY3
TRAY4
MFP
PAG E 0000 Setting number of the test print copies
COLOR ON Selecting either color/monochrome print
* When ON is specified, ON/OFF setting for each
color becomes available.
OFF
DUPLEX 2 PAGES STACK Duplex (2-sided) print is performed by the stack of
two sheets of paper.
Selecting OFF for duplex (2-sided) print.
Duplex (1-sided) print is performed by the stack of
one sheet of paper.
OFF
1PAGES STACK
item only. (The setting item is not saved in EEPROM.)
Note! PAGE setting
Pressing the [ 2] key or the [8] key shifts the digit. Pressing the [
＊
] key
increments the setting value. Pressing the [2] key increments the setting
value. If print is executed while the number of print copies remains in
"0000", printing will continue infinitely.
COLOR setting
When the [ 6] key is pressed while ON is set, the following contents are
displayed on the panel.
Print setting for each color
Pressing the [ 2] key or the [8] key shifts the setting. Pressing the [
＊
] key
or the [#], the ON/OFF switchover will be set. Pressing the [4] key returns
the panel display.
COLOR Y:ON M:ON
ON C:ON K:ON
To Next Page
