45376001TH Rev.1
131 /
Oki Data CONFIDENTIAL
5. Maintenance Menu
5.2.1.12 LED head serial number display
This self-diagnostic menu item is used to check whether the downloaded LED head data
matches the serial number of the actual LED head.
1. Enter the self-diagnostic mode (level 1) and press the [2], [8] key until "LED
HEAD DATA" is displayed in the upper row of the display area. (Pressing the [2]
key increments the test item and pressing the [8] key decrements the test item.)
Press the [6] key when "LED HEAD DATA" is displayed in the display area.
2. When the [2] key or the [8] key is pressed, serial numbers of the K/Y/M/C LED
head data are displayed in order.
3. Pressing the [4] key terminates the test. (Returns to the status of step 1.)
K ** ** ** ****
xxxxxxxxxxxxx
** ** ** ****: Rev number
xxxxxxxxxxxxxxxx: serial number
5.2.1.13 NVRAM parameter setting
Do not use this menu item.
5.2.2 Various prints with the printer as a standalone unit
Menu map print
Information of the program version number and that of the control block configuration are
printed out.
Operation:
While the system is in the [Ready To Print] state, press the [6] key once to
display [Print Information].
Press the [6] key to display [Configuration/Execute].
Press the [6] key.
Network information print
Operation:
While the system is in the [Ready To Print] state, press the [6] key once to
display [Print Information].
Press the [6] key.
Press the [2] key several times to display [Network/Execute].
Press the [6] key.
Demo print
Prints the demo patterns of the various destinations that are saved in the ROM.
Operation:
While the system is in the [Ready To Print] state, press the [6] key once to
display [Print Information].
Press the [6] key.
Press the [2] key several times to display [Demo Page/Execute].
Press the [6] key.
