45376001TH Rev.1
188 /
Oki Data CONFIDENTIAL
7. Troubleshooting and repair procedure
Check item Check work
Action to be taken
at NG
(14-2-2) Check the system connection
Check the system
connection from
the PU board to the
option tray board
(GOH-11 PCB).
Check that the cable between the PU board
option connector
to the option tray board is
normally connected.
Correct the
connections.
Square connector
connecting the
option tray unit to
the printer.
Check if any foreign material exists in the
connecting portion of the square connector.
Remove the
foreign material.
Square connector
connecting the
option tray unit to
the printer.
Is the terminals of the square connector
damaged?
Replace the
connector.
(14-2-3) Check the control signals.
Check the control
signal that is output
from the PU board to
the option tray board
(GOH-11 PCB).
Check the control signal that is output from the
PU board option connector
.
Pin-5: TXD (PU
2nd)
Pin-3: RXD (2nd
PU)
Replace the PU
board.
7.5.4. (15) LED head cannot be recognized. (error code CE82, CE83, CE84, CE85)
(15-1) Service call CE82 to CE85 (LED HEAD Missing)
Check item Check work
Action to be taken
at NG
(15-1-1) Check the system connection
Connecting condition
at the PU board
connector and at the
head connector.
Check the connecting condition of the FFC by
the visual inspection.
Correct the
connection
to the normal
connecting
condition.
Head FFC Remove the head FFC from the printer. Check
if any open-circuit or peeling-off of sheath has
occurred or not throughout the cable.
Replace the
head FFC or the
PU board.
Conduction of the
fuse on the PU
board.
Check that 5V appears across the capacitor
CP8. (Refer to section 7.6.)
Check if the fuses F8 and F9 are not open-circuit
or not.
Replace the PU
board.
To Next Page
