Oki MC760 User Manual

45376001TH Rev.1
116 /
Oki Data CONFIDENTIAL
5. Maintenance Menu
Table 5-2 SWITCH SCAN details
<Item having no function> Asterisk mark (*)
is displayed in the lower row of display area.
* 1: “L” is displayed when the cover is opened.
Display area, upper row
1 2 3 4
Details
Display area,
lower row
Details
Display area,
lower row
Details
Display area,
lower row
Details
Display area,
lower row
PAPER ROUTE : PU Entrance sensor 1
H: No paper
L: Paper exists
Entrance sensor 2
H: No paper
L: Paper exists
Write sensor
H: No paper
L: Paper exists
Exit sensor
H: No paper
L: Paper exists
TONER SENS Toner sensor K
H: Light is interrupted
L: Reflected
Toner sensor Y
H: Light is interrupted
L: Reflected
Toner sensor M
H: Light is interrupted
L: Reflected
Toner sensor C
H: Light is interrupted
L: Reflected
CVO UP_LU_FU Cover open switch
H: Close
L: Open
ST_FD_FU JOBOFF Stacker down sensor
H: No paper
L: Paper exists
REG L/R_OHP_WG Color registration sensor L
AD value:
***H
Color registration sensor R
AD value:
***H
HT THERMISTER
Fuser thermistor, upper
sensor
AD value:
***H
Fuser thermistor, lower
sensor
AD value:
***H
Fuser thermistor, upper
sensor, side
AD value:
***H
Heater frame thermistor
AD value:
***H
HUM_TEMP_DEN Humidity sensor
AD value:
***H
Temperature sensor
AD value:
***H
Density sensor (k)
AD value:
***H
Density sensor (YMC)
AD value:
***H
BELT_LVPS Belt thermistor
AD value:
***H
Power thermistor
AD value:
***H
ID UP/DOWN ID UpDown Sns
H: Down
L: Up
RFID COLOR*1 RFID antenna K
UID:
***H
RFID antenna Y
UID:
***H
RFID antenna M
UID:
***H
RFID antenna C
UID:
***H
T1 PE_PNE_CVO Tray 1 paper end sensor
H: No paper
L: Paper exists
T1 HOP_LIFT Tray 1 Hopping Sns
H: No paper
L: Paper exists
T1 CASETTE SIZE*1 Size setting switch 1 Port level H, L Size setting switch 2 Port level H, L Size setting switch 3 Port level H, L Size setting switch 4 Port level H, L
T2 PE_PNE_CVO_CA Tray 2 paper end sensor
H: No paper
L: Paper exists
T2 HOP_LF_FED 2nd-Hopping Sns
H: No paper
L: Paper exists
Tray 2 entrance sensor
H: No paper
L: Paper exists
T2 CASETTE SIZE*1 Size setting switch 1 Port level H, L Size setting switch 2 Port level H, L Size setting switch 3 Port level H, L Size setting switch 4 Port level H, L
T3 PE_PNE_CVO Tray 3 paper end sensor
H: No paper
L: Paper exists
T3 HOP_LF_FED 3rd-Hopping Sns
H: No paper
L: Paper exists
Tray 3 entrance sensor
H: No paper
L: Paper exists
T3 CASETTE SIZE Size setting switch 1 Port level H, L Size setting switch 2 Port level H, L Size setting switch 3 Port level H, L Size setting switch 4 Port level H, L
T4 PE_PNE_CVO Tray 4 paper end sensor
H: No paper
L: Paper exists
T4 HOP_LF_FED 4th-Hopping Sns
H: No paper
L: Paper exists
Tray 4 entrance sensor
H: No paper
L: Paper exists
T4 CASETTE SIZE Size setting switch 1 Port level H, L Size setting switch 2 Port level H, L Size setting switch 3 Port level H, L Size setting switch 4 Port level H, L
DUP IN_RA_FNT
Duplex (2-sided printing)
entrance sensor
H: No paper
L: Paper exists
Duplex (2-sided printing)
front sensor
H: Paper exists
L: No paper
DUP SK_CVO
Duplex (2-sided printing)
bottom sensor
H: No paper
L: Paper exists
Duplex (2-sided printing)
cover sensor
H: Close
L: Open
OFSTP E-G Stapler install signal
H: No installed
L: Installed
Stapler error signal
H: Normal
L: Abnormal
