Oki MC760 User Manual

45376001TH Rev.1
134 /
Oki Data CONFIDENTIAL
5. Maintenance Menu
Item1 Item2 Item3 Item4
Value
(Step)
Default
value
ODA
Default
value
OEL
Default
value
JP
Notes
Scanner
Maint
Adjust Scan
Pos
FBS Side Reg. +42 ~ 0 0 0 0 Adjust the scanning start position of main scanning direction when book scanning.
Front Edge +30 ~ -30 0 0 0 During book scanning, add a value for the basic value (= 5 mm) when reading the
shadow of the front edge of the document.
Adjust in intervals of one step = 4/600 dpi (= 0.17 mm).
ADF
(Front-side)
Side Reg. +42 ~ 0 +21 +21 +21 Adjust the scanning start position of main scanning direction when ADF scanning.
Front Edge +30 ~ -40 0 0 0 When reading a document from the ADF, add a value for the basic value when reading
the shadow of the front edge of the document. To skip the front edge of the document,
add a negative value.
Increase or decrease the number of motor pulses from detection by the sensor of the
front edge of the media until actual reading starts.
Adjust in intervals of one step = 4/600 dpi (= 0.17 mm).
Back Edge +30 ~ -40 0 0 0 When reading a document from the ADF, add a value for the basic value when skipping
the back edge of the document. To read the shadow of the back edge of the document,
add a negative value.
Increase or decrease the number of motor pulses from detection by the sensor of the
back edge of the media until actual reading ends.
Adjust in intervals of one step = 4/600 dpi (= 0.17 mm).
ADF
(Back-side)
Front Edge +30 ~ -40 0 0 0 When reading a document from the ADF, add a value for the basic value when reading
the shadow of the front edge of the document. To skip the front edge of the document,
add a negative value.
Increase or decrease the number of motor pulses from detection by the sensor of the
front edge of the media until actual reading starts.
Adjust in intervals of one step = 4/600 dpi (= 0.17 mm).
Back Edge +30 ~ -40 0 0 0 When reading a document from the ADF, add a value for the basic value when skipping
the back edge of the document. To read the shadow of the back edge of the document,
add a negative value.
Increase or decrease the number of motor pulses from detection by the sensor of the
back edge of the media until actual reading ends.
Adjust in intervals of one step = 4/600 dpi (= 0.17 mm).
Adjust ADF
Scan Pos
+30 ~ -30 0 0 0 Set the CIS reading position of the ADF for the focusing standard.
Adjust in intervals of one step = 4/600 dpi (= 0.17 mm). This is correlated to adjustment
of the ADF front edge position.
(3) Display "Scanner Maint" as the Scanner Maintenace Menu show below.
