Olivetti d-COLORMF3000 - Installing a Working Table WT-P01

Working Table WT-P01 14-7
c—Four screws
d—Two screws
e—Two clamps
" Use this part when installing the Authentication Device (IC card type).
Store the part in a safe place for future use.
Installing a Working Table WT-P01
1 Using a coin, turn the screws (c)
to install the mounting plate.
c
b
