151
Chapter 10 Specifications
Remote control Angulation Air pressure angulation mechanism
Function of
buttons
ZOOM (T/W) lever
Magnification of zoom changes smoothly.
BRT/MARK button
<In the live screen>
Brightness changes in UP/DOWN format.
<BRT/MARK button in the thumbnail screen>
Selects multiple images to delete, copy, or move.
ANGLE/LOCK joystick
Used to control the angulation.
MEAS/ENTER joystick
Used for menu selections and measuring
MENU/EXIT button
Toggles the menu display on and off.
LIVE/GAIN button
Returns to the live screen from the menu screen
Switches the gain mode in the live screen.
FRZ/REC button
Freezing function and recording function done by one
button.
Short push opens freeze screen.
Long push activates recording function.
INDEX button
Short push displays most recent image on retrieve screen.
Long push opens thumbnail screen.
CLEANING button
Blows air out of distal end to clean optical AD lens.
CENT button
Centers the angulation section.
Dimensions 143 (W) x 39 (D) x 40 (H) mm
(Not including the connection cable)
Weight Approx. 206 g (Including cable)
