Chapter 4 Basic operations

4.4 Disconnecting the air

 When using piped air

1 Turn the lock ring on the air connector for the piped air 90° in the

UNLOCK direction, pinch the tip of the air connector for the piped

air and remove it.

 When using a CO

cartridge

1 Tighten the cartridge dial by turning it in the CLOSE direction until

it will not turn anymore.

Cartridge dial
