Chapter 2 Instrument nomenclature and functions
2.4 LCD monitor nomenclature and functions
Shade
[ROTATE] button
Press either button to
adjust the brightness of
the LCD monitor back
light.
[POWER] switch
Press to turn on
the LCD monitor.
LCD monitor holding screw
[BRIGHTNESS] buttons
The LCD monitor can
be detached or
attached by loosening
this screw.
[TITLE] button
Rotates the LCD
monitor image by 180°.
Starts up the title
input window.
[NOTE] button
Starts up the note
input window.
LCD cable
LCD monitor holding section
