19
Chapter 2 Instrument nomenclature and functions
Storage in the optical adapter case
Store the optical adapter and the large and small O-rings in the optical adapter
case.
NOTE
There are two types of O-rings, a large one for the side of the tip of the insertion tube and a
small one for the cleaning nozzle.
Optical adapter
Large and small O-rings
Optical adapter case
