Chapter 4

Basic operations

4.1 Turning on the power

 Turning the power on

1 Press and hold the [POWER] button on the instrument for 2

seconds, the [POWER] indicator lights so you can check if the

power is on.

NOTE

• Also ensure that the [POWER] button of the LCD monitor is turned on.

Turning off the power

Press and hold the [POWER] button on the instrument for one second to turn off

the [POWER] indicator.

NOTE

• The power turns off about 3 seconds after pressing the [POWER] button.

[POWER] button

[POWER] indicator
