Chapter 3 Preparation and inspection before observation

8 Connect the air cartridge to the air connector and after it clicks into

place turn the lock ring 90° in the lock direction to prevent it from

coming off during inspections.

CAUTION

• Be careful to not injure yourself when tightening the air connector for the CO

cartridge.

cartridge air connector

Air supply connector
