Chapter 10 Specifications
10.2 Other specifications
Optical system Field of view Can be changed according to the optical adapter.
Optical adapter for stereo measurement can also be
attached.
Direction of view Variable for direct viewing or side viewing depending
on the optical adapter.
Depth of field Refer to specifications for depth of field for optical
adapter.
Illumination LD (laser diode) light source
Wavelength : 400 to 700 nm (CW)
Beam Divergence : 150°
Maximum power : 1 mW
Laser class
Class 2 (IEC60825-1 Edition 2
-2007
)
Distal end Outer diameter φ 8.5 mm
Distal end rigid
section length
See the distal end rigid section length specification of
the optical adapter in use.
Angulation 60°
UP, DOWN, RIGHT and LEFT each direction.
When a 2 meter length of the insertion tube is
extended straight.
Flexible section Flexibility Hose of consistent stiffness from distal end of insertion
tube to the instrument.
Outer diameter φ 8.4 mm
Index lines An orange line is drawn 500 mm from the distal end of
the insertion tube.
Also, thin white lines are drawn on the insertion tube at
1000 mm intervals from the distal end. The number of
white lines increases every 1000 mm (1 line at 1000
mm, 2 lines at 2000 mm).
A thick white line is drawn 5000 mm from the distal end
of the insertion tube, after that, for every increase in
1000 mm a thick and a thin white line are added.
A thick white line appears again at 10,000 mm from the
distal end of the insertion tube, after that the thick and
thin white lines increase as before.
Total length 30 m
