Chapter 10 Specifications
RECORDING CARD slot One CF card slot for recording cards and optical data
cards for stereo measurement.
A CF card (1 GB) is included as a recording card.
Operation is not certified except with the card provided
or cards recommended by Olympus.
Input/Output
connector
Video signal
outputs
Two video signal outputs
(For external devices)
(1) Composite (VBS) video output
One BNC jack output.
(2) Y/C (S) video output
One S video connector output
Video output standards:
Based on RS170A format (full commonality)
Output impedance 75 ohm (full commonality)
Microphone
input
φ3.5 mm monaural mini jack
(for plug-in power)
USB connector A connector, Ver.1.1 standards
Extension
connector
AUX connector
Internal laser diode Wavelength : 450 nm (CW)
Beam Divergence : 9°
Maximum power : 0.8 W
Power supply Battery Specified battery can be inserted and removed from
the battery slot.
Only the specified battery is permitted:
Specified battery (Lithium Ion)
Model name:
Manufactured by IDX NP-L7S
Nominal voltage: 14.8 V
Battery powered operating time:
120 minutes or longer (based on with a new
battery)
For details, refer to the instruction manual of your
battery.
AC adapter Designated AC adapter can be connected to AC
adapter connector.
Rated input voltage : 100 V to 240 V
Supply frequency : 50/60 Hz
Output voltage : 16 V
For details, refer to the instruction manual of AC
adapter.
