Chapter 2 Instrument nomenclature and functions

CAUTION

• Be sure to connect the optional MH-888 S-video cable (option) with core to the S-video

connector.

Connect the plug with core of the S-video cable to the S-video connector of the instrument.

AC adapter cover

Battery cover

I/F connector cover

Aux connector

USB connector

RECORDING CARD

slot

Slot cover

S-video connector

Video connector

Mic connector

AC adapter connector

Pressure

regulator

Air supply

connector

[LIGHT] button

[LIGHT] indicator

[POWER] indicator

[POWER] button
