Chapter 3 Preparation and inspection before observation

4 Loosen the cartridge dial by turning it in the OPEN direction until it

will not turn anymore.

5 Confirm that the pressure indicator gauge is between 0.6 and 0.8

MPa.

Cartridge dial

Pressure indicator
