Olympus OM System OM-1 - Names of parts

15 EN
Names of parts
Names of parts
1
2
3
4
5
6
9
8
7
0
a
n
o
m
l
e
f
g
h
i
j
k
b
c
d
1 Mode dial lock .................................P. 39
2 Mode dial ........................................P. 39
3 F (Exposure compensation) button
..............................P. 43, 45, 47, 50, 106
4 R (Movie)/ h (High Res Shot)/
H (selection) button
..................................P. 59/P. 156/P. 197
5 Shutter button .................................P. 39
6 Front dial (k)
.................. P. 43 – 50, 63, 188, 205, 216, 218
7 Self-timer lamp/AF illuminator
.............................................P. 126/P. 96
8 Y (One-touch white balance) button
......................................................P. 152
9 Z (Preview) button .......................P. 224
0 Lens attachment mark ....................P. 26
a Mount (Remove the body cap before
attaching the lens.)
b Stereo microphone ...............P. 180, 199
c ON/OFF lever ................................P. 30
d v button .......................................P. 223
AFm (AF/metering mode) button
......................................................P. 109
jY# (Sequential shooting/self-timer/
ash) button ..........................P. 120, 126
e External flash terminal ..................P. 119
f Microphone jack cover
g Cover for headphone jack.............P. 181
h Connector cover
i Strap eyelet.....................................P. 18
j Lens release button ........................P. 28
k Lens lock pin
l
Microphone jack (ø3.5 mm stereo mini-
jack for third-party microphones) ...P. 180
m Headphone jack (ø3.5 mm stereo mini-
jack for third-party headphones) ...P. 181
n HDMI connector (Type D)
..........................................P. 182, P. 288
o USB connector (Type C)
..................................P. 22, 23, 283, 287
