Omni 7000 Series Installation Guide

OMNI 4000/7000 Installation Guide – Rev H
4-67
Configuration
11.
a. Fill in the remaining information in
the Meter Pressure screen.
b. When you are finished, click Apply
to save the changes.
12.
a. Select and expand Density or
Density/Gravity to display its
configuration options.
b. Configure the associated
Temperature and Pressure items if
either is included in your meter run.
When a Density is configured, a Density Temperature and a Density Pressure input
channel should also be configured, even if they share the same input channels as the
Meter Temperature and Meter Pressure.
13.
In the main Density or Density/Gravity
display screen, select an I/O Point using
the drop-down box and fill in the remaining
information on the other screens, as
needed.
14.
a. Under Density or
Density/Gravity, select Temperature.
Select an I/O Point, and fill in the
information in the Temperature
screen.
b. When you are finished, click Apply
to save the changes.
Press F1 to access
OMNICONNECT Help for
assistance.
Press F1 to access
OMNICONNECT Help for
assistance.
